SPECIFICATION （All the parameters are measured under
230VAC input，more than 10% of rated load，and 25℃ of ambient temperature）
| Item | Specifications |
|---|---|
| Output Voltage Selectable | 5V;12V;24V |
| Overload protection | Built-in |
| Short circuit protection | Hiccup mode, recovers automatically after fault condition is removed |
| Over voltage protection | Built-in |
| Withstand voltage | IP-OP:3000Vac; IP-PE:1500Vac;OP-PE:500vdc |
| Working temperature | -40~70℃ |
| Start-up Time | <3Sec |
| Safety standards | GB4943/EN60950 |
| EMCstandards | IEC61000-4 |
| Connection | 9.5mm screw terminial |
| Dimension(L*W*H) | 267±1mm×60±1mm×33.5±1mm |
Model List
| FS-400-12Model | Input | Output | Current | R&N | Effi | Temp | Storage temperature |
|---|---|---|---|---|---|---|---|
| FS-200-5 | AC90-305V | 5V | 40A | <300mV | 87% | -40-70℃ | -40℃-85℃ |
| FS-200-12 | AC90-305V | 12V | 16.7A | <300mV | 88% | -40-70℃ | -40℃-85℃ |
| FS-200-24 | AC90-305V | 24V | 8.3A | <300mV | 87% | -40-70℃ | -40-70℃ |
